Powerful shear has a wide application in steel structure demolition and recycling and construction waste processing.
Item No :
hydraulic power shear JSDF220 for 12-20ton excavatorOrder(MOQ) :
1unitPayment :
50% deposite,and the balance before shipmentProduct Origin :
chinaColor :
as required by clientsShipping Port :
shanghaiLead Time :
35daysWeight :
1600kgApplication:
Features:
We have obtained CE certificate, ISO certicate for our heavy-duty attachments.
We use HARDOX imported from sweden and NM400 to our powerful shear.
Rotary 360 hydraulic units with swivel shear is adopted.
Double cylinder synchronous power system is equipped
.
| Item/Model | Unit | JSDF40M | JSDF80 | JSDF220 | JSDF290-II | JSDF310 | JSDF400 | JSDF450 | JSDF550 | JSDF600 |
| Suitable Excavator | ton | 3-5 | 6-9 | 12-20 | 20-30 | 25-35 | 30-40 | 35-45 | 40-45 | 45minimum |
| Weight | kg | 360 | 750 | 1600 | 2850 | 3050 | 4050 | 4450 | 5800 | 6500 |
| Working Pressure | bar | 200 | 250 | 300 | 320 | 320 | 320 | 320 | 320 | 320 |
| Working Flow | L/min | 60 | 150 | 250 | 280 | 280 | 350 | 350 | 350 | 350 |
| Opening A | mm | 335 | 435 | 600 | 690 | 740 | 790 | 800 | 820 | 860 |
| Cutting Depth B | mm | 280 | 330 | 460 | 500 | 550 | 620 | 650 | 650 | 720 |
| Overall Length C | mm | 1160 | 1420 | 1899 | 2210 | 2345 | 2590 | 2700 | 3010 | 3167 |
| Blade Length D1/D2 | mm | 180+130 | 210+155 | 300+210 | 300+260 | 350+260 | 350+330 | 350+360 | 380+360 | 400+360 |
| Shearing Force a | ton | 37 | 62 | 108 | 150 | 156 | 250 | 260 | 300 | 320 |
| Shearing Force b | ton | 24 | 43 | 75 | 100 | 118 | 150 | 160 | 170 | 180 |
| Rotation Diameter | mm | 360 | 593 | 752 | 752 | 806 | 806 | 922 | 922 |
Powerful shear hydraulic double cylinder sheaer is used in steel structure demolition, scrap metal recycling,vehicle dismantling, and construction waste processing. We adopt industrial-grade wear-resistant steel NM400, upgraded sealing system,so that it provides superior durability and consistent output.
View More
Powerful shear is used in steel structure demolition and recycling and construction waste. We use NM400, upgraded sealing system,so that it provides superior durability and consistence.
View More
Powerful shear has a wide application in steel structure demolition and recycling and construction waste processing. It's made of NM400 with upgraded sealing system,so that it provides better durability and consistence.
View More
